Maxinmum working pressure: / 8.5 / 10.5 bar(g) ( equivalent to 109 / 123 / 152 psig)
Capacity(FAD): 8.24-16.48 / 8.18-16.36 / 6.41-12.82 m³/min ( equivalent to 291-582 / 289-578 / 227-453 cfm)
Installed motor power: 90 kW; 120 hp
Driving Mode & Cooling Method: Direct Driven; W-Water Cooling
Noise level db(A): 73
Dimensions(mm) LxWxH: 2400x1700x1800 mm
Weight (kg): 2300
Air outlet pipe diamete: DN65
*) FAD in accordance with ISO 1217 : 2009, Annex C: Absolute intake pressure 1 bar (a), cooling and air intake temperature 20°C
**) Noise level as per ISO 2151 and the basic standard ISO 9614-2, operation at maximum operating pressure and maximum speed; tolerance: ± 3 dB(A) change without notice.
Specifications are subject to change without notice.
