DriveTest FM300BT Closing Force Transducer for elevator doors, machine protection devices (0~750 N)

- FM300 BT: Bluetooth

Measuring range: 0 ... 750 N

Accuracy: +/– 3 N or 3 % of reading

Stiffness: 25 N/mm

Gap width: 145–510 mm / 5.7-20" (incl. extension set)

Diameter: 58 mm / 2.2"

Measuring principle: DMS transducer

Dimensions: 280 x 145 x 82 mm / 11.0 x 5.7 x 3.2"

Weight: 1.2 kg / 2.6 lb

- PC evaluation software PinchPilot:

Multilingual (DE, EN, IT, FR, ES)

Graphic representation of the force curve

Calculation of important parameters

Evaluation according to different guidelines (standards)

Possibility of entering self-defined guidelines

Log printout

Data export (Excel, CSV, PDF)

- App downloadable from the Google Play Store

Force Meter - easy-to-use app with automatic guidelines and standards updates

Time saving - immediate feedback on the measurement result including simpler report generation

Paperless office - reduces paper and the associated costs and protects the environment

Can be used individually - integration of the customer's signature possible

- System requirements software PinchPilot and app (see tab Software/App)

Delivery Scope:

1 x Closing force transducer FM300 BT

1 x App Force Meter available for download

1 x Software PinchPilot (USB stick)

1 x PC connection cable (USB)

1 x Manual

1 x Transport case with foam insert

1 x ISO calibration certificate
