Mains Power Supply
• Input voltage: 90 – 264 V AC, 50/60 Hz
• Input power: 110 VA
String current
• Range: ± 500 A
• Resolution: 0.1 A
Typical accuracy: ± 300 V DC (string voltage channels): ± (0,5 % rdg + 0.1 % F.S)
Control Unit and module communication
• RS485 serial communication
Communication with PC
• Ethernet
Environment conditions
• Temperature: 20 °C to +55 °C / -4 °F - +131 °F
• Maximum relative humidity: 0 – 95 %, non-condensing
Dimension: 399 mm x 240 mm x 115 mm/ 15.7 In x 9.44 in 4.52 in
Weight: 4.1 kg / 9.0 lbs
