Weight: 136 g
Accuracy: ± 0.25 %
Compliance: CE
Display Type: N/A
Accuracy Note: ± 0.25% FS @ 77°F (25°C)
Mounting Note: Vertical
Output Detail: Field Selectable
Output Signal: Current, Voltage
Pressure Type: Differential
Pressure, Max: 100 inH₂O
Pressure, Min: 0 inH₂O
Proof Pressure: Up to 15 psi
Supply Voltage: 2-Wire: 10 to 35 Vdc, 3-Wire: 17 to 36 Vdc/21.6 to 33 Vac
Loop Resistance: Current Output: 0 to 1250 Ω max, Voltage Output: Load resistance 1 kΩ min.
Number of Wires: 2, 3
Span Adjustment: Push Button
Thermal Effects: ± 0.036% FS/°C
Electrical Output: 4 to 20 mA, 0 to 10 Vdc
Power Consumption: max 40 mA
Supply Power Type: AC/DC
Long Term Stability: ± 1%/year
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases
Mounting Orientation: 1.378" DIN rail
Electrical Connection: Screw Terminal
Process Connection Note: 1/8˝ female NPT. Accessories included are 2 barbed fittings for 1/8˝ (3.12 mm) and 3/16˝ (4.77 mm) ID rubber or vinyl tubing
Process Connection Size: 1/8 in
Process Connection Type: NPT Female
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -10 °C
Zero Setting Adjustable Range: Push button
