Weight: 567 g
Accuracy: ± 1 %
Materials: ABS
Compliance: CE, RCM
Display Type: N/A
Accuracy Note: ± 1% from -5 to 60°C (23 to 140°F)
Mounting Note: Not Position Sensitive
Output Signal: Voltage
Pressure Type: Differential
Pressure, Max: 15 psi
Pressure, Min: 0 bar
Response Time: 50 ms
Burst Pressure: 115 psi Maximum
Proof Pressure: Up to 70 psi
Supply Voltage: 12 to 36 Vdc/12 to 32 Vac
Loop Resistance: 2 kΩ load max
Static Pressure: 360 psi
Electrical Output: 0 to 10 V
Enclosure Ratings: IP65
Materials, Wetted: 304 Stainless Steel, Alumina Ceramic, EPDM, Silicone
Power Consumption: max 13 mA
Relative Humidity: 10% to 90% non-condensing
Supply Power Type: AC/DC
Long Term Stability: ± 1% FS/year
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Oxygen, Steam
Electrical Connection: DIN 43650 A (solenoid valve)
Process Connection Size: 1/4 in
Process Connection Type: NPT Female
Process Temperature, Max: 80 °C
Process Temperature, Min: -10 °C
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -10 °C
