Weight: 330 g
Accuracy: ± 0.4 %
Compliance: CE
Display Type: N/A
Accuracy Note: ± 0.4% FS* at room temperature
Output Signal: Current
Pressure Type: Differential
Pressure, Max: 0.1 inH₂O
Pressure, Min: -0.1 inH₂O
Response Time: 10 ms
Proof Pressure: Up to 15 psi
Supply Voltage: 16 to 32 Vdc
Loop Resistance: 0 to 800 Ω
Number of Wires: 2
Span Adjustment: Potentiometers
Thermal Effects: <0.028% FS/°F
Electrical Output: 4 to 20 mA
Enclosure Ratings: IP65, NEMA Type 4
Materials, Wetted: 302 Stainless Steel, Brass, Glass, Nickel, Silicone
Supply Power Type: DC
Long Term Stability: ± 1% FS/year
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases
Thermal Effects Note: (Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).
Process Connection Note: OD barbed brass pressure fitting
Process Connection Size: 3/16 in
Process Connection Type: Barbed Fitting
Storage Temperature, Max: 105 °C
Storage Temperature, Min: -54 °C
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -18 °C
Compensated Temperature, Max: 85 °C
Compensated Temperature, Min: -18 °C
Zero Setting Adjustable Range: Internally accessible potentiometers, non interactive
