Weight: 8.8 oz
Accuracy: ± 5 %
Baud Rate: N/A
Compliance: CE
Wire Gauge: 16 AWG
Display Type: N/A
Probe Length: 9.45 in
Output Detail: 4 to 20 mA
Output Signal: Current
Response Time: 5 s @ 90%
Data Interface: N/A
Inrush Current: 85 mA; 10 V
Probe Diameter: 0.75 in
Supply Voltage: 20 to 26 Vdc
Load Resistance: 700 Ω
Number of Digits: N/A
Air Velocity, Max: 1575 FPM
Air Velocity, Min: 0 FPM
Enclosure Ratings: IP67, NEMA Type 6
Power Consumption: 60 mA + Output Current
Relative Humidity: 0 to 90% RH Non-Condensing
Supply Power Type: DC
Media Compatibility: Argon, Carbon dioxide, Clean Dry Air, Helium, Nitrogen, Non-Corrosive Dry Gases
Mounting Orientation: None
Electrical Connection: Cable Gland for 4 to 8 mm Wire with Screw Terminal block
Enclosure Ratings Note: NEMA 6 (IP67) Except Sensing Point
Operating Temperature, Max: 122 °F
Operating Temperature, Min: 32 °F
