Accuracy: ± 1 % + 1 count
Mounting: 180° Gimbal Mounting with 30° Stops or Bezel Mount
Impedance: Set Voltage: >1 M Ω (>10 M Ω on 200 mV range); Adjustable Voltage: 392 kΩ; Adjustable Current: 300 Ω
Input Type: Voltage, Current
Display Type: LED
Warm Up Time: 10 min
Sampling Rate: 3 Hz (3 updates/second)
Supply Voltage: 90 to 250 Vac
Number of Digits: 3.5
Supply Power Type: AC
Current Input Range: Adjustable Current: 0(4)-20 mA dc
Voltage Input Range: ± 200 mVdc, ± 2 Vdc, ± 20 Vdc,
Display Segment Color: Red
Display Segment Height: 58 mm (2.3 in)
Storage Temperature, Max: 167 °F
Storage Temperature, Min: -40 °F
Number of Display Segments: 7
Operating Temperature, Max: 122 °F
Operating Temperature, Min: 14 °F
