Weight: 230 g
Accuracy: ± 1 %
Compliance: CE
Wire Gauge: 26 to 16 AWG
Display Type: N/A
Accuracy Note: ± 1% FSO
Mounting Note: Not Position Sensitive
Output Detail: Field Selectable
Output Signal: Current, Voltage
Pressure Type: Differential
Pressure, Max: 1 inH₂O
Pressure, Min: -1 inH₂O
Response Time: 3 s
Burst Pressure: 6 psi Maximum
Proof Pressure: Up to 3.5 psi
Supply Voltage: 2-Wire: 10 to 36 Vdc, 3-Wire: 17 to 36 Vdc/21.6 to 33 Vac
Loop Resistance: Current Output: 0 to 1250 Ω max, Voltage Output: Load resistance 1 kΩ min.
Number of Wires: 2, 3
Span Adjustment: Push Button
Electrical Output: 4 to 20 mA, 0 to 5 Vdc, 0 to 10 Vdc
Enclosure Ratings: IP66, NEMA Type 4X, UL94 V-0, UL 2043 (Plenum)
Materials, Wetted: Consult Factory
Power Consumption: max 21 mA
Supply Power Type: AC/DC
Response Time Note: Instantaneous (default) or 3 s (selectable)
Long Term Stability: ± 1% FSO/year
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases
Mounting Orientation: Wall Mount
Electrical Connection: 1/2 NPS female Conduit with Screw Terminal block
Process Connection Size: 1/8 in, 3/16 in, 1/4 in
Process Connection Type: Stepped Barb Fitting
Operating Temperature, Max: 70 °C
Operating Temperature, Min: -20 °C
Material Construction Option: N/A
Zero Setting Adjustable Range: Digital push-button
