Detected gases:R-12, R-123, R-125, R-134a, R-143, R-22, R-404a, R-407c, R-410a, R-507, R-514a, R-1234yf, R-1234ze etc
Default calibration: R-404a
Sensing method:metal-oxide semiconductor
Sampling method: Diffusion
Sensor lifetime: > 5 years
Power supply: 24 VDC/AC ±20% (default) or 230 VAC (optional)
Digital interface: UART
Output relays: 2 × SPST relays (switch-over contact), 250 VAC / 30 VDC, 5A max
Alarms:blinking LED, buzzer 85 dB
Default Alarm setpoints: 200 ppm / 400 ppm halocarbon gas
Enclosure: grey ABS plastic, wall mount, IP65
Dimensions: H90 × W145 × D55 mm
Operating conditions: -30...+60 °C, <95 %RH (non-condensing)
