Specifications:
Temperature range: -13 to 1202°F (-25 to 650°C)
Basic accuracy:±1% of reading or ±1°C (2°F), whichever is greater
Image storage capacity:50,000 JPEG images (with spot temperature metadata tag)
Emissivity:0.10 to 0.99 (adjustable) and 3 presets
Response time:150 ms
IR Resolution:80 x 60 (4800 pixels)
Digital Camera Resolution:2 MP (megapixels)
Thermal Sensitivity /NETD:< 70 mK
Field of View (FOV):51° x 66 (H x W)°
Minimum focus distance:0.3 m (0.89 ft.)
Distance to Target:30:1
Dual range operation:Range 1: < 752°F (400°C); Range 2: > 752°F (400°C) - For Range 2, the high temperature lever must be engaged
Focus:Fixed
Image frequency:8.7 Hz
Focal plane array/Spectral response range:Uncooled microbolometer/7.5 ~ 14 μm
Display resolution:320 x 240 pixels
Screen size:2.4" (61 mm) - portrait
Viewing angle:80°
Display type:TFT technology
Image modes:Visual and Visual/Thermal MSX (Multi-Spectral Dynamic) images
Color display palettes:Iron, Rainbow, White-hot, Black-hot, Arctic, and Lava
Image gallery:Yes
IP rating:IP54 (IEC 60529)
Drop tested:~6.5 ft (2 m)
Accessory mount:UNC 1/4"-20
Power:Internal rechargeable battery (3.6 V Lithium Ion)
Dimensions/Weight:8.3 x 2.5 x 3.2" (210 x 64 x 81 mm)/13.9 oz (394 g)
