Width: 3.93 mm
Height: 4.7 mm
Length: 4.7 mm
Technology: Si
Unit Weight: 240 mg
Configuration: Single
Mounting Style: Through Hole
Transistor Polarity: PNP
Pd - Power Dissipation: 625 mW
DC Current Gain hFE Max: 300
Gain Bandwidth Product fT: 200 MHz
Emitter- Base Voltage VEBO: 5 V
Collector- Base Voltage VCBO: 60 V
Continuous Collector Current: 800 mA
Maximum DC Collector Current: 800 mA
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Collector- Emitter Voltage VCEO Max: 60 V
Collector-Emitter Saturation Voltage: 1.6 V
