IR resolution : 320 × 240 pixels
Resolution with UltraMax® : —
MSX® image enhancement : Yes: details from visual camera add depth and perspective
Built-in visual camera : 5 MP, fixed focus, with built in LED light
Thermal sensitivity : <40 mK @ 30°C (86°F)
Temperature range: -20°C to 120°C (-4°F to 248°F); 0°C to 650°C (32°F to 1202°F)
Optional temperature range : —
Accuracy: ±2°C (±3.6°F) or ±2% of the reading
Focus modes : Manual
Digital zoom : 1–4x continuous
Measurement tools: 3 spotmeters in live mode, 1 area meter in live mode
Measurement presets: None, center spot, hot spot, cold spot ; 3 spots, Hot Spot-spot
Available lenses : 24° (fixed lens)
1-Touch Level/Span : Yes: automatic contrast enhancement
Laser pointer : Yes
Area measurement information: —
On-camera routing software : FLIR Inspection Route™ with baseline image comparison and image overlay guidance
On-camera report building : Voice annotation and GPS tagging to images and video; on-screen text; sketch on infrared images from touchscreen
FLIR software integration FLIR Thermal Studio Suite, FLIR Research Studio:
Radiometric JPEG : Yes
IR, radiometric, visual video recording : Yes
IR, radiometric, visual video streaming: Yes, over UVC (radiometric, non-radiometric, visual) and Wi-Fi (non-radiometric, visual)
Communication modes : USB 2.0, Bluetooth®, Wi-Fi, DisplayPort
Cloud services : FLIR Ignite™ for automatic uploading of images directly from the camera to the cloud for easy, secure storage, editing, sharing, and reporting
METERLiNK® : Yes via Bluetooth
Display : 640 × 480 pixels (VGA) Dragontrail® touchscreen
Drop-testing : 2 m (6.6 ft)
Battery operation time : >2.5 hours, typical use
