IR resolution: 240 × 180
Thermal sensitivity/NETD: <40 mK @ 30°C (86°F)
Field of view (FOV): 51° × 38°
Image frequency: 60 Hz
Detector type: Focal plane array (FPA), uncooled microbolometer
Spectral range: 7.5 - 13.5 µm
Pitch: 25 µm
Display: 4-inch LCD, 320 × 240 pixels, backlit
Object temperature range: -20°C to 150°C (-4°F to 302°F), 0°C to 650°C (32°F to 1202°F)
Accuracy: ±4°C (±7.2°F) or ±4% of reading, for ambient temperature 10°C to 35°C (50°F to 95°F)
Non-radiometric IR video streaming: Uncompressed colorized video using USB
USB: USB Mini-B
Interfaces:
Update from PC devices
Data transfer to and from PC
General
Battery: 3.6V / 4.4Ah Li-ion, approximately 4-hour operating time
Charging system:
2-bay charger
Optional In-truck charger
Charging time: 2 h to 85% capacity, charging status indicated by LEDs
Start-up time: <17 s. (IR image, no GUI)
Camera weight, including battery: 1.1 ±0.05 kg (2.4 ±0.1 lb)
Camera size (L × W × H): 120 mm × 125 mm × 280 mm (4.7 in × 4.9 in × 11 in)
Tripod mounting: UNC ¼"-20 (adapter needed)
Operating temperature range:
-20°C to 60°C: (-4°F to 140°F)
150°C (302°F): 15 min.
260°C (500°F): 5 min.
Storage temperature range: -40°C to 85°C (-40°F to 185°F)
Encapsulation: IP 67 (IEC 60529)
