IR Resolution: 464 × 348 pixels
Thermal Sensitivity/NETD: <40 mK, 24° @ 30°C (86°F)
Accuracy: ±2°C (±3.6°F) or ±2% of reading
Digital Camera: 5 MP, with built-in LED photo/video lamp
Display: 4", 640 × 480 pixel touchscreen LCD with auto-rotation
Storage Media: Removable SD card
IMAGING & OPTICAL
Camera software update: Using USB cable or SD card
Color: Black
Color Palettes: Iron, Gray, Rainbow, Arctic, Lava, Rainbow HC
Detector Type and Pitch: Uncooled microbolometer, 17 µm
Digital Camera: 5 MP, with built-in LED photo/video lamp
Digital Camera FOV: 53° × 41°
Digital Zoom: 1–6× continuous
Field of View: 24° × 18°
f-number: 1.3, 24°
Focal Length: 17 mm (0.67 in.), 24°
Focus: Continuous with laser distance meter (LDM), one- shot LDM, one-shot contrast, manual
Frame Rate [Full Window]: 30 Hz
Gallery: Yes
Image Frequency: 30 Hz
IR Resolution: 464 × 348 pixels
Laser Alignment: Position is automatically displayed on the infrared image
Lens: 24°
Lens Identification: Automatic
Minimum Focus Distance: 0.15 m (0.49 ft.), 24°, Macro mode 71 µm as option to 24°
Minimum Focus Distance with MSX: 0.5 m (1.64 ft.), 24°
NETD: <40 mK
Non-radiometric IR video streaming: H.264 or MPEG-4 over Wi-Fi MJPEG over UVC or Wi-Fi
Picture-in-Picture: Resizable and movable
Radiometric IR video recording: Real-time radiometric recording (.csq)
Radiometric IR video streaming: Over UVC
Resolution: 464 × 348 pixels (VGA)
Spatial resolution (IFOV): 0.90 mrad/pixel, 24°
Spectral Range: 7.5 - 14 µm
Thermal Sensitivity/NETD: <40 mK, 24° @ 30°C (86°F)
UltraMax: Quadruples pixel count; activated in menu and processed in FLIR Tools
Video Lamp: Built-in LED light
Viewfinder: No
Visual Image: Yes
Visual Video Recording: H.264 to memory card
Visual Video Streaming: Yes
MEASUREMENT & ANALYSIS
Accuracy: ±2°C (±3.6°F) or ±2% of reading
Automatic hot & cold detection: Automatic maximum/minimum markers within area
Color Alarm (Isotherm): •Above •Below •Interval •Condensation (moisture/humidity/dewpoint) •Insulation
Difference Temperature: Yes
Emissivity Correction: Yes, variable from 0.01 to 1.0 or selected from materials list
Measurement Corrections: Yes
Measurement Function Alarm: Audible/visual alarms (above/below) on any selected measurement function
Measurement Presets: •No measurements •Center spot •Hot spot •Cold spot •User preset 1 •User preset 2
Object Temperature Range: -20°C to 120°C (-4°F to 248°F) 0°C to 650°C (32°F to 1202°F) 300°C to 1500°C (572°F to 2732°F) There are no optional ranges
Reference Temperature: Yes
USER INTERFACE
Display: 4", 640 × 480 pixel touchscreen LCD with auto-rotation
Display Technology: IPS
Languages: 21
Text: Predefined list or touchscreen keyboard
Touch Screen: Optically bonded PCAP
Voice: 60 sec. recording added to still images or video via built-in mic (has speaker) or via Bluetooth
POWER
Battery operating time: Approx. 4 hours at 25°C (77°F) ambient temperature and typical use
Battery Type: Li-ion battery, charged in camera or on separate charger
Battery voltage: 3.6 V
Battery weight: 195 g (6.89 oz.)
Charging system: In camera (AC adapter or 12 V from a vehicle) or two-bay charger
Charging Temperature: 0°C to 45°C (32°F to 113°F)
External Power Operation: AC adapter 90–260 V AC (50/60 Hz) or 12 V from a vehicle (cable with standard plug, optional)
Power Management: Automatic shut-down and sleep mode
