AC Current (45 to 400 Hz)
Range: 60.00 A ~ 600.0 A
Resolution: 0.01 A ~ 0.1 A
Accuracy: 2% + 10, 2% + 5
AC Voltage (45 to 400 Hz)
Range: 600.0 V
Resolution: 0.1 V
Accuracy: 1.5% + 5
DC Voltage
Range: 600.0 V
Resolution: 0.1 V
Accuracy: 1% + 5
Resistance
Range: 600.0 Ω, 6.000 kΩ, 60.00 kΩ
Accuracy: 1% + 5
Voltage Frequency
Range:
9.999 Hz
99.99 Hz
999.9 Hz
9.999 kHz
99.99 kHz
Accuracy: 0.1% + 3
Current Frequency
Range: 45.0 to 400.0 Hz
Accuracy: 0.1% + 3
Capacitance
Range: 9.999 µF, 99.99 µF, 999.9 µF
Accuracy: 2% + 5, 5% + 5
Diode Test
Range: 3.000 V
Accuracy: 10%
General Specifications
Maximum Voltage between any terminal and earth ground: 300 V
Maximum differential voltage between V/Ω and COM terminals: 600 V
Display (LCD): 6000 counts, 3 updates/second
Battery Type: 2 × AAA, IEC LR03
Battery Life: Minimum 500 hours
Auto Power Off: 20 minutes
Temperature
Operating: -10 °C to 50 °C
Storage: -30 °C to 60 °C
Relative Humidity
Non-condensing (<10 °C)
≤ 90% RH at 10 °C to 30 °C
≤ 75% RH at 30 °C to 40 °C
≤ 45% RH at 40 °C to 50 °C
Altitude
Operating: 2000 m
Storage: 12000 m
Temperature Coefficient: 0.1 × (accuracy) /°C (<18 °C or >28 °C)
Dimensions (H × W × L): 190 × 52 × 16 mm
Weight: 132 g
Jaw Opening Size: 34 mm
Protection Class: IP30
