Pressure control range: -13 to 600 psi, -90 to 4000 kPa, -0.90 to 40 bar
Pressure type: Gauge/absolute (Depends on the type of internal or external pressure module
Pressure accuracy and Control stability: 0.02% of FS, 0.005% of FS
Replaceable pressure measurement modules: Yes, 4 modules
mA sourcing/measurement: Yes
Voltage measurement: Yes
Loop power: 24 V dc
Pressure switch testing: Yes
Pressure leakage testing: Yes
HART Communication: Yes, basic commands supported
Autostep / auto ramp: Yes (with customizable speed, mode and style)
Battery: Rechargeable lithium battery with charge indication (charged in the instrument or separately)
Language: English
Electrical specification
All specifications are valid to 110% of range, except 24 mA source and simulate which are valid to 100% of range.
Ranges
mA measure, source and simulate: 0 mA to 24 mA
Volts dc measurement: 0 V dc to 30 V dc
Resolution
mA dc source, simulate and measure: 1 μA
Voltage dc measurement: 1 mV
Accuracy: 0.01% FS ±2 LSD all ranges (at 23 °C ±5 °C)
Stability: 20 ppm FS /°C (-10 °C to +18 °C and 28 °C to 50 °C)
mA simulation working voltage: 12 V dc to 30 V dc
Loop compliance voltage: 24 V dc @ 20 mA
Temperature measurement , 100 Ω Pt(385) RTD: -50 °C to 150 °C
Temperature resolution: 0.01 °C
Temperature accuracy: ±0.1 °C ±0.25 °C combined uncertainty when using 720 RTD probe (optional accessory)
Drive capability (mA source): 1200 Ω (without HART resistor), 950 Ω (with internal HART resistor)
Mechanical specification
Dimension (HxWxL): 290 x 215 x100 mm, (4.3 x 4.4 x 9.4 in)
Weight: 4.9 kg, (10.8 lbs)
Environmental specification
Operating temperature: -10 °C to 50 °C
Pressure control: 0 °C to 50 °C
Battery charging: 0 °C to 40 °C
Storage temperature: -20 °C to 60 °C
Operating altitude: <3000 m
Storage altitude: <13000 m
Operating humidity:
Non-condensing (<10°C)
≤90 % RH (10 °C to 30 °C)
≤75 % RH (30 °C to 40 °C)
≤45 % RH (40 °C to 50 °C)
