Measurement type:Hall sensor
Nominal current range: 400 A, AC/DC
Continuous current range: 1 A - 400 A AC/DC
Maxium non-destructive curren:400 A
Lowest measureable current: 0.5 A
Basic accuracy: 3.5% + 0.5 A(% reading + floorspec)
Useable frequency: DC - 3 kHz
Output level(s): 1 mV/A
Zerro error adjustmemt:Yes
Safety: Specifications
Safety: CAT III, 600 V
Maximum voltage: 600 V
Output cable length: 1.6 m
Shrouded banana plugs: Yes
| Measurement type | Hall sensor |
| Nominal current range | 400 A, AC/DC |
| Continuous current range | 1 A - 400 A AC/DC |
| Maxium non-destructive current | 400 A |
| Lowest measureable current | 0.5 A |
| Basic accuracy | 3.5% + 0.5 A (% reading + floorspec) |
| Useable frequency | DC - 3 kHz |
| Output level(s) | 1 mV/A |
| Zerro error adjustmemt | Yes |
| Safety Specifications | |
| Safety | CAT III, 600 V |
| Maximum voltage | 600 V |
| Mechanical and General Specifications | |
| Warranty | 1 year |
| Battery life | 9 V, 60 h |
| Maximum conductor diameter | 30 mm 2 x 25 mm |
| Output cable length | 1.6 m |
| Shrouded banana plugs | Yes |
