Field of View (FOV): 49° × 37°
Spatial Resolution (IFOV): 2.67 mrad
Minimum Imaging Distance: 0.4 m
Focus Mode: Focus free
Complete Temperature Range: -20℃ ~ 450℃ (-4 ~ 842 ℉)
Accuracy: ±2℃ (3.6 ℉) or ±2%, whichever is greater (Ambient temperature 15~35℃ (59~95 ℉), target object temperature >0℃, calibration at 1 meter)
Image Frame Rate: 30 Hz
Measurement Spot: 20
Measurement Line: 10
Measurement Area: 10
Image Mode: Thermal image, Digital camera, Picture in Picture & T-DEF® blend
T-DEF®: Support, thermal and visible light image blend, transparency 0% ~ 100%
T-TWB®: Support histogram thermal color display
Infrared Resolution: 320 × 240
IR Detector Type: Ceramic-packaged detector, uncooled FPA infrared detector
Thermal Sensitivity (NETD): 40 mK (0.04℃) @30℃ (86 ℉)
Detector Pitch: 12 μm
Spectral Range: 8 – 14 μm
PC Software: AnalyzIR®
Display Screen: 3.5 inch Touch Screen
Palettes: 6 Palettes
Digital Camera: 5 MP industrial camera
Storage Card: TF card, max 32GB
File Format: Radiometric thermal photo (JPEG), digital camera photo
Battery Type: Rechargeable Li-ion, 3.6V, 5000mAh
Battery Operating Time: ≥ 5 hours
Language: English
