Flow rate: 9000 LPH
Working vacuum: -0.06 ～ -0.095 MPa
Working pressure: ≤0.5 MPa
Working without Trouble: ≥4000 H
Continuous Working: ≥150 H
Temperature range: 20 ～ 80 ℃
Power supply: 380V, 3 phase, 50 Hz (or as per your requirements)
Working noise: ≤ 61 ~ 85 dB（A）
Heating power: 60 KW
Total power: 65 KW
Inlet/outlet caliber: φ50 mm
Gross Weight: 700 KGS
Dimension L×W×H: 1700 × 1150 × 1900 mm
Oil Results after Oil Purifier System
Moisture (Water Content): ≤ 5 PPM
Gas Content: ≤0.1% (Vol)
Impurities Degree (Filtration precision): ≤ 5 micron (no free carbon)
Breakdown Voltage (Dielectric): ≥65 ~ 70 KV
Flash Point: ≥130℃
Cleanliness: ≤NAS 1638 Grade 6
