Leak Measurement
Leak ranges:
0 to 60.00 cc/h (1.000 cc/min)
0 to 200.0 cc/h (3.333 cc/min)
0 to 600.0 cc/h (10.00 cc/min)
0 to 2000 cc/h (33.33 cc/min)
Accuracy @ 20°C:
10% to 100% range: < ± (1% reading + 1 digit)
0 to 10% range: < ± (0.1% range + 1 digit)
Resolution 4 digit display.
Temperature Coefficients:
Zero: Automatic
Span: < ±0.15% per °C
Long Term Drift (span) < ±1% per year
Pressure Measurement
Pressure Ranges:
5 to 99.99 mbar
20 to 400.0 mbar
50 to 999.9 mbar
0.2 to 2.000 bar
1 to 4.000 bar
3 to 8.000 bar
Accuracy @ 20°C:
10% to 100% range: < ± (1% reading + 1 digit)
0 to 10% range: < ± (0.1% range + 1 digit)
Resolution 4 digit display
Temperature Coefficients:
Zero: < ±0.05% per °C
Span: < ±0.1% per °C
Long Term Drift (span) < ±1% per year
Electrical
Supply Voltage 24VDC ±10% < 1A
Electrical connections
Power: 2 way detachable screw terminal
Outputs: 20 way detachable terminal
Inputs: 16 way detachable terminal
RS232: 9 pin D plug
RS485: 5 pin detachable screw terminal
LAN: RJ45 connector, 10base-T/100base-TX Ethernet
USB: 1 x USB Type A connector, 1 x USB Type B connector
Control Inputs Up to 24 Opto-isolated, active high or active low. 5VDC to 24VDC into 10K
Control Outputs Up to 32 Active High transistor output (PNP). 12VDC to 45VDC, 120mA (per channel)
Pneumatic:
Media Compatibility Clean dry air or non-corrosive gas
Air Supply Pressure Maximum 10bar gauge, Minimum 5bar gauge
Regulator Supply Pressure Maximum 16bar gauge
Pneumatic Connections
Air supply: 6mm push-in tube connector
Regulator supply and output: 8mm push-in tube connector
Test/Reference: 1/8” BSPF with adaptation for 6mm O/D push-on tubing.
Up to 5 programmable pneumatic outputs: 4mm push-in tube connectors
Leak Tightness < 0.2cc/Hour
Construction:
Enclosure Steel construction enclosure with paint finish. Suitable for 19” 3U rack mounting.
Dimensions – Rack Case 482 x 133 x 296 mm (W x H x D)
Dimensions – Bench Case 366 x 154 x 296 mm (W x H x D)
Weight 9 kg ± 0.5 kg
