Current clamp jaw size: 50mm
Out Singal: AC:1V/10A, AC:1V/100A, AC:1V/1000A
Accuracy: 0.5%
Standard color: Blue
Power: 9V dry battery
External power supply: 8-12V
Power consumption: 6mA
Standard Interface: BNC
Function: AC leakage current, high current, high harmonic current, complex waveform current, phase, electric energy, power, power factor, etc.
Phase Error: ≤1°(@50Hz ; 23°C+2°C)
Turn Ratio and Output: can be customized
Out Interface: Can be customized others
Output Line Length: Pliers to adapter 50cm, signal output 2m
Output mode: current-induced output
Sheathing material: ABS
Line Voltage: Line Test under AC 1000V
Working Temperature: -25°C to +60 °C
Insulation Resistance: 100MΩ @ 500Vdc
Medium strength: AC3700V/rms (between iron core and shell)
Frequency Characteristics: 10Hz~ 100kHz
