Power: DC3.7V lithium battery
Display mode: color LCD display, 72×55mm
Instrument size: W/L/T: 187*119*48mm
Jaw size: Ø8mm
Voltage range: AC 0.00V-600V/Resolution: 0.01V/Accuracy: ±0.5% FS
Current range: AC 0.0mA-20.0A/Resolution: 0.1mA/Accuracy: ±0.5% FS
Phase range: 0.0°-360.0°/Resolution: 0.1°/Accuracy: ±1°
Frequency range: 45.00Hz-65.00Hz/Resolution: 0.01Hz/Accuracy: ±0.5Hz
Active power range: 0.0W～12kW/Resolution：0.1W/ Accuracy：±(3%rdg+3dgt)
Reactive power range: 0.0W～12kVAR/ Resolution：0.1VAR/ Accuracy：±(3%rdg+3dgt)
Apparent power range: 0.0W～12kVA/ Resolution：0.1VA/ Accuracy：±(3%rdg+3dgt)
Power factor range: -1～+1/ Resolution：0.001/ Accuracy：±0.03
Detection rate: About 2 second/time
Data hold: Press HOLD key to hold data during test, "H" symbol display
Automatic shut-down: About 15 minutes after power on, the meter will automatically shut down
Backlight function: have, Suitable for dark places and night use
Voltage detection: When the battery voltage is lower than 3.2V, the battery voltage is low symbol display
USB interface: USB interface, uploading data to a computer for analysis of management data
Instrument weight: Host: 362g(including battery), Tip-shaped current clamp: 180g*2, Test line: 190g
Voltage test line length: 1.5m
Current clamp line length: 2m
Working temperature and humidity: -10℃～40℃；below 80%Rh
Storage temperature and humidity: -10℃～60℃；below 70%Rh
