Standards applied
Regulations: 2006/95/EC - 2004/108/EC - EN61326-1:2006 - EN6101G-1:2010 - EN61010-2-010:2003
Performance
Temperature Range: +5 Ta ... 85 °C
Capacity: 22 L
Minimum overall height with lid fully closed: 150 mm
Temperature Resolution: 0.1 °C
Temperature fluctuation at 37 °C: ±0.1 °C
Temperature variation in space at 37 °C: ±0.2 °C
Volume: 22 L
Display: LCD
Timer: 99:59 hh:mm
Security Class (DIN 12880): 2
Circulation Type: Forced circulation
Pump: Yes
Maximum Pump Flow Rate [l/min]: 12 l/min
Power: 1100 W
Inner Tank Depth: 200 mm
Overtemperature Safety System: Electronic
Discharge valve: Yes
Rack capacity: 8 slot
Feeds
Frequency: 50 - 60 Hz
Power Supply: 230 V
Dimensions and weight
Weight: 19 kg
External dimension (W x D x H): 680 x 365 x 390 mm
Packaging dimension (W x D x H): 450 x 800 x 570 mm
Internal Tank dimension (W x D x H): 500 x 295 x 200 mm
Bottom Plate Dimensions: 450 x 265 mm
