Gain: 15.8 dB, 32.4 dB
Technology: GaAs
Isolation dB: 30 dB, 44 dB
Mounting Style: SMD/SMT
Test Frequency: 3.3 GHz to 4.2 GHz
Input Return Loss: 5.5 dB, 6.7 dB
NF - Noise Figure: 0.65 dB, 0.68 dB
Number of Channels: 1 Channel
Operating Frequency: 2.3 GHz to 2.7 GHz, 3.3 GHz to 4.2 GHz, 4.4 GHz to 5 GHz
Operating Supply Current: 28 mA, 66 mA
Operating Supply Voltage: 5 V
P1dB - Compression Point: 22 dBm
OIP3 - Third Order Intercept: 24.9 dBm, 32 dBm
Maximum Operating Temperature: + 115 C
Minimum Operating Temperature: - 40 C
