IR detector
IR resolution: 384×288
Detector type: VOx/25μm/7.5~14μm
Frame rate: 25Hz/9Hz
NETD: 40mk
Focal length: 25mm/F1.0
Field of view (FOV): 21.7°×16.4°
Spatial resolution (IFOV): 0.99mrad
Min focus distance: 0.4m
Focus: Electric, Automatic
Image Presentation:
LCD display: 5",1280×720 High Light Touch Screen
Viewfinder: 1280×960 LCOS Screen
Brightness contrast: Automatic, Manual, Fixed
Image mode: IR image, Visual image, PIP, MIF
Color palette: 8
Digital zoom: 1.1~4x
Temperature Measurement
Measurement Range: 20°C~60°C
Accuracy: ≤ ±0.4℃ (target temperature 32℃~38℃)
Spot/Line/Area: 5 spots, 5 lines, 5 Areas
Other
Hardware: Visual camera of 5 million pixels, Illuminator, laser, Wi-Fi, Microphone (Volume adjustable), Speaker (Volume adjustable), Digital compass, GPS, Light sensor
Interface: Micro USB 2.0,SD card,Gigabit Ethernet,Tripod,Mini HDMI
Battery: Rechargeable Li-ion Battery(Certified to UN38.3), battery time > 4 hours, support Sleeping mode
Working Temperature: 15°C~35°C
Storage Temperature: ﹣40°C~70°C
Encapsulation: IP54
Weight: 1350g
Size: 206mm×145mm×135mm
Standard Accessories: Li-ion battery,Power supply adapter, Adapter plug (5 pcs), Shoulder strap,USB cable, HDMI cable, Network cable, Quick Start Guide, User Manual, Data Download Card, SD card(16G), Hard transport case
Optional Accessories: Tripod, wireless mouse & keyboard & Micro USB OTG cable, 24 inch monitor (HDMI interface) & changeover plug., Li-ion battery, Pouch, Battery charger, Bluetooth earphone, Extended lens, Lens bag
