IR resolution: 192×144 pixels
Detector type: VOx/25μm/7.5~14μm
Frame rate: 25HZ/9HZ
NETD: 50mk
Focal length: 7mm/F1.1
Field of view(FOV): 37.8°×28.8°
Spatial Resolution(IFOV): 3.45mrad
Min focus distance: 1m
Focus: Focus-free
Temperature range: -20℃~350℃
Accuracy: ±2℃ or ±2% of reading for ambient temperature 15°C to 35°C and object temperature above 0°C
Measurement Area (IR/PIP): 5 X Spot; 2 X Line:; 5 X Area
Temperature range: Operating: -10℃~50℃; Storage: -40℃~70℃
Weight: 735g
Dimensions(mm): 274×97×78
EncapsulationIP54
CertificationCE, FCC, ROHS
Standard Accessories: Li-ion battery, Power supply adapter, Adapter plug, Wrist strap, USB cable, HDMI cable, Quick Start Guide, User Manual, Data Download Card, Capacitive screen gloves, TF card (16GB), Hard transport case
Optional Accessories: Li-ion battery, Pouch, Battery charger, Tripod mount interface, Sunshield, Bluetooth earphone, Extended lens
