Thermal
Detector Type: Cooled 320x256
Spectral Range: 3~5μm
Pitch: 30μm
Lens
Focal Length: 33-500mm Optical Zoom
F#: 4
Detection Range: 30km (to vessel)
Recognition Range: 8km (to vessel)
Visual
Focal length: 12.5-750mm continuous
Visual Video: HD-SDI 1080P
Laser Dazzler
Laser Wavelength: 532±0.1 nm
Detection Range: 1000m
Laser Range
Accuracy: ±5m
Distance: 8km
Servo Platform
Azimuth Angle: -170°-170° or Nx360 optional
Pitching Angle: -40°-90°
Stabilized: ≤0.2mrad (1σ)
DVR
Capacity: 2T
Display
Type: Technical LCD (Customization)
Resolutions: 1600x1200
Power
Voltage: Cabinet: AC220V/50Hz
Power Consumption: Cabinet: ≤2000W
Interface
Control: RS422
Video Output: IR: PAL BNC TV: HD-SDI BNC
Expand: RS232 DB9
Environmental Characteristics
Working Temperature: Cabinet: 0°C-40°C
Storage Temperature: Cabinet: -10°C-50°C
Rain/Shock/Vibration/Humidity/Salt Spray: Cabinet: GB/T 6994
Physical Parameter
Weight: Cabinet: ≤150kg
Size: Platform: φ408±5mm Height: 584mm±5mm
Cabinet: 625mm±5mm×974mm±5mmx1507mm±5mm
