Imaging and optics:
Detector type: WLP Vox
Infrared resolution: 256×192
Pixel pitch: 12μm
Wavelength range: 8~14μm
Field angle: 56°±1°
Netd netd: ≤55mK
Infrared frame rate: 25Hz
Focusing mode: Focus-free
Measurement and analysis:
Measurement range: -20℃~550℃ (-20~150℃|100~550℃ two modes for automatic temperature measuring)
Measurement accuracy: ±2℃ or ±2%
External interface: 40PIN BTB connector
Data format: USB 2.0
Power supply and power consumption:
Voltage: 3.3V±0.3V
Typical power consumption: ＜700mW
Software kit:
Sdk sdk: Android, Linux, Windows
Demo software: PC/Android
Environmental parameters:
Working temperature: -20℃~60℃
Storage temperature: -40 ℃~85℃
Certification: RoHS
Physical parameters:
Weight: ＜10g
Size: About 21×2mm
