Input ratings (AC rms)
Nominal input voltage: 200 Vac ~ 240 Vac
Input voltage range: 180 Vac ~ 264 Vac
Phase: Single phase, Two-wire
Nominal input Frequency: 50 Hz ~ 60 Hz
Input frequency range: 47 Hz ~ 63 Hz
Max. power consumption: ≤ 2500 VA
Power factor 200Vac: 0.95 (TYP)
Max. input current 200Vac: 15 A
AC mode output ratings (AC rms)
Voltage
Setting Range: 0.0 V ~ 200.0 V / 0.0 V ~ 400.0 V
Setting Resolution: 0.1 V
Accuracy: ±(1 % of set + 1 V / 2 V)
Output phase: Single phase, Two-wire
Maximum current
100 V: 20 A
200 V: 10 A
Maximum peak current
100 V: 120 A
200 V: 60 A
Load power factor: 0 ~ 1 (leading phase or lagging phase)
Power capacity: 2000 VA
Frequency
Setting range AC Mode: 40.0 Hz ~ 999.9 Hz, AC+DC Mode: 1 Hz ~ 999.9 Hz
Setting resolution: 0.01 Hz (1.00 ~ 99.99 Hz), 0.1 Hz (100.0 ~ 999.9 Hz)
Accuracy: 0.02% of set (23 °C ± 5 °C)
Stability: ± 0.005%
Output on phase: 0° ~ 359° variable (setting resolution 1°)
DC offset: Within ± 20 mV (TYP)
Output rating for DC mode
Voltage
Setting Range: -285 V ~ +285 V / -570 V ~ +570 V
Setting Resolution: 0.1 V
Accuracy: ±(1 % of set + 1 V / 2 V)
Maximum current
100 V: 20 A
200 V: 10 A
Maximum peak current
100 V: 120 A
200 V: 60 A
Power capacity: 2000 W
Output voltage stability
Line regulation: 0.2%
Load regulation: ≤ 0.5% (0 ~ 100%, via output terminal)
Ripple noise: 1 Vrms / 2 Vrms (TYP)
Output voltage waveform distortion ratio, Output voltage response time, Efficiency
Total harmonic distortion(THD):
≤ 0.2% @50/60Hz
≤ 0.3% @<500Hz
≤ 0.5% @500.1Hz~999.9Hz
Output voltage response time: 100 us (TYP)
Efficiency: ≥ 80 %
General
Display: TFT-LCD, 4.3 inch
Operating temperature range: 0 °C ~ 40 °C
Storage temperature range: -10 °C ~ 70 °C
Dimensions (WxHxD): 430mm × 176mm × 550mm
Weight: Approx. 25 kg
Standard accesorries:
Safety information, CD-ROM, Input/Output Cover, EIA Rack Mount, USB Cable
Optional accessories:
GPW-005 Power Cord, 3m, 105℃, UL/CSA Type
GPW-006 Power Cord, 3m, 105℃, VDE Type
GPW-007 Power Cord, 3m, 105℃, PSE Type
GRA-442-J Rack Mount Adapter(JIS)
GTL-137 Output Power Wire(Load wire_10AWG: 50A, 600V/ Sense wire_16AWG: 20A, 600V)
GTL-232 RS232C cable, approx. 2m
GTL-248 GPIB Cable, approx. 2m
ASR-002 External Three Phase Control Unit for 1P2W, 1P3W, 3P4W output (CE application in progress)
APS-008Air inlet filter
