Function | Range (*2) | Resolution | Input Resistance | Accuracy(*1) |
DC Voltage | 500.00 mV | 10μV | 10MΩ or >10GΩ | 0.02 + 4 |
5.0000 V | 100μV | 10MΩ or >10GΩ | 0.02 + 4 | |
50.000 V | 1mV | 11.11MΩ | 0.02 + 4 | |
500.00 V | 10mV | 10.1MΩ | 0.02 + 4 | |
1000.0 V | 100mV | 10MΩ | 0.02 + 4 | |
Resistance | 500.00 Ω | 10mΩ | 0.83mA | 0.10 + 5 (*3) |
5.0000 kΩ | 100mΩ | 0.83mA | 0.10 + 3 (*3) | |
50.000 kΩ | 1Ω | 83μA | 0.10 + 3 | |
500.00 kΩ | 10Ω | 8.3μA | 0.10 + 3 | |
5.0000 MΩ | 100Ω | 830nA | 0.10 + 3 | |
50.000 MΩ | 1kΩ | 560nA//10 MΩ | 0.30 + 3 | |
DC Current | 500.00 μA | 10nA | 0.06V max. | 0.05 + 5 |
5.0000 mA | 100nA | 0.6V max. | 0.05 + 4 | |
50.000 mA | 1μA | 0.14V max. | 0.05 + 4 | |
10μA | 1.4V max. | 0.10 + 4 | ||
100μA | 0.5V max. | 0.25 + 5 | ||
1mA | 0.8V max. | 0.25 + 5 | ||
Continuity | 5000.0 Ω | 100mΩ | 0.83mA | 0.10 + 5 |
Diode Test | 5.0000 V | 100μV | 0.83mA | 0.05 + 5 |
Capacitance | 5.000 nF: 0.5~1nF | 0.001nF | 8.3μA | 2.00 + 20 |
5.000 nF: 1~5nF | 0.001nF | 8.3μA | 2.00 + 10 | |
50.00 nF: 5~10nF | 0.01nF | 8.3μA | 2.00 + 30 | |
50.00 nF: 10~50nF | 0.01nF | 8.3μA | 2.00 + 10 | |
500.0 nF | 0.1nF | 83μA | 2.00 + 4 | |
5.000 μF | 1nF | 0.56mA | 2.00 + 4 | |
50.00 μF | 10nF | 0.83mA | 2.00 + 4 | |
True RMS Volatge (*4/*5/*6) | 500.00 mV | 10μV | 30Hz – 50Hz | 1.00 + 40 |
50Hz – 10kHz | 0.50 + 40 | |||
10kHz – 30kHz | 2.00 + 60 | |||
30kHz – 100kHz | 3.00 + 120 | |||
5.0000 V | 100μV | 30Hz – 50Hz | 1.00 + 20 | |
50Hz – 10kHz | 0.35 + 15 | |||
10kHz – 30kHz | 1.00 + 20 | |||
30kHz – 100kHz | 3.00 + 50 | |||
50.000 V | 1mV | 30Hz – 50Hz | 1.00 + 20 | |
50Hz – 10kHz |
