Output Ratings
Independent: 0 V ~ 20 V, 0 A ~ 5 A
Series (2 units): 0 V ~ 40 V, 0 A ~ 5 A
Parallel (2 units): 0 V ~ 20 V, 0 A ~ 10 A
Constant Voltage Operation
Line Regulation: ≤ 0.01 % + 3 mV
Load Regulation: ≤ 0.01 % + 5 mV
Ripple & Noise: ≤ 0.5 mVrms (5 Hz to 1 MHz)
Setting Range: 0 V ~ 21 V
Setting/Readback Accuracy: ± (0.03 % of reading + 10 mV)
Setting/Readback Resolution: 1 mV / 0.1 mV
Max Remote Sensing Compensation Voltage: 1 V
Recovery Time: ≤ 100 µs (50 % load change, minimum load 0.5 A)
Temperature Coefficient: ≤ 300 ppm/°C
Constant Current Operation
Line Regulation: ≤ 0.2 % + 3 mA
Load Regulation: ≤ 0.2 % + 3 mA
Ripple & Noise: ≤ 2 mArms
Setting Range: 0 A ~ 5.25 A
Setting/Readback Accuracy: ± (0.3 % of reading + 10 mA)
Setting/Readback Resolution: 0.1 mA / 0.01 mA
Temperature Coefficient: ≤ 300 ppm/°C
Protection
OVP Range: OFF, ON (1.0 V ~ 22.0V))
OVP Resolution: 100 mV
OVP Accuracy: ≤ ± 100 mV
OCP Range: OFF, ON (0.25 A ~ 5.5 A)
OCP Resolution: 10 mA
OCP Accuracy: ≤ ± 20 mA
Display
2.4-inch TFT LCD
Insulation
Chassis – Terminal: ≥ 20 MΩ (DC 500 V)
Chassis – AC Cord: ≥ 30 MΩ (DC 500 V)
Environment
Operation: Indoor, Altitude ≤ 2000 m; 0 °C to 40 °C; RH ≤ 80 %; Installation category II; Pollution degree 2
Storage: -10 °C to 70 °C; RH ≤ 70 %
Power Source & Consumption
AC 100 V, 120 V, 220 V, 240 V ± 10 %, 50/60 Hz
Power Consumption: 300 VA
Dimensions & Weight
107 mm × 124 mm × 313 mm (W × H × D)
Approx. 5.2 kg
