Rated output voltage: 1500 V
Rated output current: 20 A
Rated output power: 10000 W
Output power ratio: 3
Constant Voltage Mode
Line regulation [0.01 % of Vo_rated]: 150 mV
Load regulation [0.02 % of Vo_rated]: 300 mV
Ripple and noise (p-p): 2400 mV
Ripple and noise (r.m.s.): 400 mV
Temperature coefficient: 100 ppm/°C from rated output voltage, following 30 minutes warm-up.
Remote sense compensation voltage (5 % of Vo_rated): 75 V
Rise time (Rated load): 30 ms
Rise time (No load): 30 ms
Fall time (Rated load): 80 ms
Fall time (No load): 1200 ms
Transient response time: 1.5 ms
Constant Current Mode
Line regulation [0.05 % of Io_rated]: 10 mA
Load regulation [0.1 % of Io_rated]: 20 mA
Ripple and noise (r.m.s.): 22 mA
Temperature coefficient: 100 ppm/°C from rated output current, following 30 minutes warm-up.
Protection Function
Over voltage protection (OVP) - Setting range: 5.00 V to 1650.0 V
Over voltage protection (OVP) - Setting accuracy: 1500 V
Over current protection (OCP) - Setting range: 2.00 A to 22.00 A
Over current protection (OCP) - Setting accuracy: 40 mA
Over power protection (OPP) - Setting range: 200 W to 11000 W
Over power protection (OPP) - Setting accuracy: 100 W
Over voltage limit (OVL) - Setting range: 0.0 V to 1575.0 V
Under voltage limit (UVL) - Setting range: 0.0 V to 1575.0 V
Over current limit (OCL) - Setting range: 0.0 A to 21.00 A
Under current limit (UCL) - Setting range: 0.0 A to 21.00 A
