Specification:
OUTPUT RATING:
Output voltage(V): 0~40
Output current(A): 0~40
Output power(W): 400W
REGULATION (CV):
Load regulation (mV): 25
Line regulation (mV): 23
REGULATION (CC):
Load regulation (mA): 45
Line regulation(mA): 45
RIPPLE & NOISE (Noise Bandwidth 20MHz ; Ripple Bandwidth = 1MHz)
CV p-p: 60
CV rms: 7
CC rms: 80
PROGRAMMING ACCURACY:
Voltage: 10 0.1% +
Current: 200.1% +
MEASUREMENT ACCURACY:
Voltage: 100.1% +
Current: 200.1% +
RESPONSE TIME:
Raise Time: 50
Fall Time(Full load): 50
Fall Time(No load): 500
Load Transient Recover Time(Load change from 50 to 100%): 1
PROGRAMMING RESOLUTION (By PC Remote Control Mode):
Voltage: 1
Current: 1
MEASUREMENT RESOLUTION (By PC Remote Control Mode):
Voltage: 1
Current: 1
SERIES AND PARALLEL CAPABILITY:
Parallel Operation: Up to 4 units including the master unit
Series Operation: Up to 2 units including the master unit
PPROTECTION FUNCTION:
OVP: 4-44
OCP: 4-44
OHP: Turn the output off.
FRONT PANEL DISPLAY ACCURACY, 4 digits:
Voltage: 20 0.1% +
Current: 200.1% +
ENVIRONMENT CONDITION:
Operation Temp: 0˚C to 40˚C
Storage Temp: -25˚C to 70˚C
Operating Humidity: 20% to 85% RH; No condensation
Storage Humidity: 90% RH or less; No condensation.
OTHER
Analog Control: Yes
Interface: USB/LAN/GPIB(Option)
Power Source: 100Vac to 240Vac, 50Hz to 60Hz, single phase
Dimension & Weight: Approx.5.2kg 214×124×350
