Specification:
OUTPUT RATING:
Output voltage(V): 0~160
Output current(A): 0~20
Output power(W): 800W
REGULATION (CV):
Load regulation (mV): 85
Line regulation (mV): 83
REGULATION (CC):
Load regulation (mA): 25
Line regulation(mA): 25
RIPPLE & NOISE (Noise Bandwidth 20MHz ; Ripple Bandwidth = 1MHz)
CV p-p: 80
CV rms: 15
CC rms: 40
PROGRAMMING ACCURACY:
Voltage: 500.1% +
Current: 200.1% +
MEASUREMENT ACCURACY:
Voltage: 500.1% +
Current: 200.1% +
RESPONSE TIME: (ms)
Raise Time: 100
Fall Time(Full load): 150
Fall Time(No load): 1200
Load Transient Recover Time(Load change from 50 to 100%): 1
PROGRAMMING RESOLUTION (By PC Remote Control Mode):
Voltage: 3
Current: 1
MEASUREMENT RESOLUTION (By PC Remote Control Mode):
Voltage: 3
Current: 1
SERIES AND PARALLEL CAPABILITY:
Parallel Operation: Up to 4 units including the master unit
Series Operation: Up to 2 units including the master unit
PPROTECTION FUNCTION:
OVP: 5-176
OCP: 2-22
OHP: Turn the output off.
FRONT PANEL DISPLAY ACCURACY, 4 digits:
Analog Control: Yes
Interface: USB/LAN/GPIB(Option)
Power Source: 100Vac to 240Vac, 50Hz to 60Hz, single phase
Dimension & Weight: Approx. 6.8kg214×124×350
