PSM-6003 | |||
DC OUTPUT | |||
| Low Range | 0~30V/6A | ||
| High Range | 0~60V/3.3A | ||
CONSTANT VOLTAGE OPERATION | |||
| Regulation + (% of output + offset) | Load regulation < 0.01% + 2mV Line regulation < 0.01% + 2mV | ||
| Ripple & Noise | ≦50V : < 500μVrms/3mVpp >50V : < 1mVrms/3mVpp | ||
CONSTANT CURRENT OPERATION | |||
| Regulation + (% of output + offset) | Load regulation < 0.01% + 250μA Line regulation < 0.01% + 250μA | ||
| Ripple & Noise | < 2mArms | ||
RESOLUTION | |||
| Programming Voltage | 2mV | ||
| Programming Current | 0.5mA | ||
| Readback Voltage | 1mV | ||
| Readback Current | 0.5mA | ||
| Front Panel Voltage | 1mV | ||
| Front Panel Current | 1mA ( <10a 10ma="" u="">>10A ) | ||
| OVP/OCP Voltage | 10mV | ||
| OVP/OCP Current | 10mA | ||
ACCURACY | |||
| Programming Voltage | 0.05% + 10mV | ||
| Programming Current | 0.2% + 10mA | ||
| Readback Voltage | 0.05% + 5mV | ||
| Readback Current | 0.15% + 5mA | ||
| OVP/OCP Voltage | 0.1% + 10mV | ||
| OVP/OCP Current | 0.4% + 10mA | ||
TRANSIENT RESPONSE | |||
| < 50μsec (for output to recover within 15mV following a change in output current from full load to half load) | |||
COMMAND PROCESSING TIME | |||
| 100ms | |||
VOLTAGE PROGRAMMING RESPONSE TIME (for resistive load) | |||
| Voltage Up Full Load | 80mS | ||
| Voltage Up No Load | 100mS | ||
| Voltage Down Full Load | 30mS | ||
| Voltage Down No Load | 450mS | ||
STABILITY (% of output + offset) | |||
| Voltage | 0.02% + 1mV | ||
| Current | 0.1% + 1mA | ||
MEMORY | |||
| Store/Recall 100 sets | |||
TEMPERATURE COEFFICIENT PER±(% of output + offset) | |||
| Voltage | 0.01% + 3mV | ||
| Current | 0.02% + 3mA | ||
INTERFACE | |||
| Standard : RS-232C, GPIB | |||
| POWER SOURCE | |||
| AC100V/120V/220V±10%, 230V-6%~+10%, 50/60Hz | |||
| DIMENSIONS & WEIGHT | |||
| 230(W) x 140(H) x 380(D)mm Approx. 10kg | |||
