Cooling capacity
KCAL/H 50/60Hz: 1250/1500
W 50/60Hz: 1450/1750
BTU/H 50/60Hz: 5000/6000
Temperature controller
A: Fixed temperature control type (setting range: 10-40 °C)
B: Differential temperature control type (tracing ambient/machine body temperature, setting range: -9.9 to +9.9 °C)
Use range
Ambient temperature: 10-40°C (Standard)
Liquid temperature: 10-30°C
Power source: 3Ø 200-230V 50/60Hz
Power Consumption
Compressor / Fan motor (W): 845 / 50
Pump (W): 80
Pump Performance (50/60Hz)
Max. flow rate (L/min): 32/38
Max. liquid lift (m): 3.8/5.4
Piping Diameter
Liquid inlet diameter: PT 3/4"
Liquid outlet diameter: PT 3/4"
Dimension WxDxH (mm): 630x420x420
Weight (KG): 65
Noise level: Below 70 dB(A)
