Accuracy: ±2 % of reading above 200 µS/cm
Cable Length: 20 ft
Cell Constant k: 10 cm⁻¹
Diameter: 32.5 mm
Digital Gateway: None
Electrode Material: Graphite
Flow: 0 - 3 m/s maximum, fully immersed
Immersion Depth 2: 33 mm tee mount
Installation style: General purpose
Junction box: None
Length: 134.6 mm
Operating Temperature Range: -20 - 200 °C
Pressure Range: 6.8 bar at 150 °C (when used with hardware, a lower rated mounting hardware or piping material may limit the temperature and pressure ratings)
Range: 0 - 200000 µS/cm
Repeatability: ±0.5 % of reading
Response Time T90: < 30 s after step change
Sensitivity: ±0.5 % of reading
Sensor Immersion Depth: 114.3 mm pipe mount
Sensor Thread: ¾" NPT at both ends
Sensor Type: Analog
Temperature Measurement: -20 - 200 °C
Temperature Sensor: Pt1000 RTD
Transmission Distance: 100 m maximum;1000 m maximum, when used with a termination box
What's included?: Includes: sensor with 6 m (20 ft) cable and manual
