Thermal Module
Image Sensor: Vanadium Oxide Uncooled Focal Plane Arrays
Max. Resolution: 160 × 120 (the resolution of output image is 320 × 240)
Pixel Interval: 17 μm
Response Waveband: 8 μm to 14 μm
NETD : Less than 40 mK (25°C), F# = 1.1
Lens (Focal Length): 6.2 mm
IFOV: 2.74 mrad
Field of View: 25.0° × 18.7° (H × V)
Min. Focusing Distance: 0.6 m
Aperture: F1.1
Optical Module
Max. Image Resolution: 2688 × 1520
Image Sensor: 1/2.7" Progressive Scan CMOS
Min. Illumination: Color: 0.0089 Lux @ (F1.6, AGC ON), B/W: 0.0018 Lux @ (F1.6, AGC ON)
Shutter Speed: 1s to 1/100,000s
Lens (Focal Length): 8 mm
Field of View: 39.42° × 22.14°(H × V)
WDR: 120 dB
Day & Night: IR cut filter with auto switch
Image Function
Bi-spectrum Image Fusion : Fusion view of thermal view and overlaid details of the optical channel
Picture in Picture: Combines details of thermal and optical image PIP, overlay thermal image on optical image
Smart Function
VCA (Video Content Analysis): 4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 8 VCA rules totally.
Temperature Measurement: 3 temperature measurement rule types, 21 rules (10 points, 10 areas, and 1 line).
Temperature Range: -20 °C to +150 °C (-4 °F to +302 °F)
Temperature Accuracy: ± 8 °C (± 14.4 °F)
Fire detection: Dynamic fire point detection, up to 10 fire points detectable.
Infrared
IR Distance: Up to 15 m
IR Intensity and Angle : Automatically adjusted
General
Menu Language: 32 languages
Power: 12 VDC ± 20%, two-core terminal block, PoE (802.3af, class 3)
Power Consumption: 12 VDC ± 20%: 0.5 A, max. 6 W, PoE (802.3af, class 3): 42.5 V to 57 V, 0.14 A to 0.22 A, max. 6.5 W
Working Temperature/Humidity: -40 °C to 65 °C (-40 °F to 149 °F), 95% or less
Protection Level: IP66 Standard, TVS 6000V Lightning protection, surge protection, voltage transient protection
Dimension: 138.3 mm × 138.3 mm × 123.1 mm (5.45 " × 5.45" × 4.85 ")
Weight: 940 g (2.07 lb)
