SPECIFICATIONS
- Measurement line type:
+ Single-phase 2-wire, single-phase 3-wire
+ Three-phase 3-wire
- Measurement items:
+ Voltage, Current, Active power, Apparent power, Reactive power
+ Power factor, Phase angle, Frequency, Efficiency
+ Current integration, Active power integration, Integrated time
+ Voltage waveform peak value, Current waveform peak value
+ Voltage crest factor, Current crest factor, Time average current
+ Time average active power, Voltage ripple factor
+ Current ripple factor
- Measurement range:
+ Voltage range: AC/DC 15 V to 1000 V, 7 ranges
+ Current range: AC/DC 200 mA to 50 A, 8 ranges
+ Power range: 3.0000 W to 150.00 kW
- Basic accuracy(Active power):
+ ±0.1% rdg. ±0.1% f.s. (DC)
+ ±0.1% rdg. ±0.05% f.s. (45 Hz to 66 Hz, at Input < 50% f.s.)
+ ±0.15% rdg. (45 Hz to 66 Hz, at 50% f.s. ≤ Input)
- D/A output:
+ 16 channels, Level output DC ±2 V, Waveform output 1 V f.s
+ Level output, instantaneous waveform output(U,I,P)
+ Level output (apparent power, reactive power, power factor, or other)
+ High-speed active power level output
- Other functions:
+ AC+DC, AC+DC Umn, AC, DC, FND, Autorange, Average
+ VT or CT ratio settings, Synchronized control
+ MAX/ MIN, or other functions
- External interfaces:
+ RS-232C
+ LAN standard
- Power supply: 100 to 240 V AC, 50/60 Hz, 40 VA max
- Product Net Weight: 5.6 kg
- Product Size: 305*132*256mm
- Supplied accessories:
+ Instruction manual ×1
+ Measurement guide ×1
+ Power cord ×1
- The warranty period: 12 month
