Pitch: 3.5 mm
Row Spacing: 5 mm
Unit Weight: 1.400 g
Housing Color: Natural (White)
Contact Gender: Socket (Female)
Current Rating: 6 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 2 Row
Voltage Rating: 300 V
Wire Gauge Max: 16 AWG
Wire Gauge Min: 22 AWG
Contact Plating: Tin
Contact Material: Phosphor Bronze
Housing Material: Polyamide (PA)
Wire Gauge Range: 22 AWG to 16 AWG
Termination Style: Crimp
Number of Positions: 10 Position
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 30 C
