Honestco MCRF50 RF Probe (50GHz)

Characteristic impedance: 50 ohm

Frequency range: DC - 50GHz

DC voltage: 100V

DC current: 1A

RF Power @ 10GHz max: 5W

Contact resistance on Au: 0.05 ohm

Insertion loss to 50GHz: -1.5dB

Insertion loss to 50GHz: -13dB

Probe Material (for RF / RF GND): Nickel Alloy or W, BeCu

Probe Material (for DC / DC GND): Tungsten(W) or BeCu

Body Material: Aluminum Alloy

XY position error: Max 10um

Planarity error: Max 10um

Available Pitch: Min 50um / Max TBD

RF Connector: 1.85mm (J)

Connector: 2.54mm Pin header/or Coax+BNC or SMA
