AC TRMS VOLTAGE
Range (V): 15~460
Resolution (V):1
Accuracy: ±(3.0%rdg + 2dgt)
FREQUENCY
Range (Hz): 47.50 ~ 52.50
Resolution (Hz): 1
Accuracy: ±(0.1%rdg + 1dgt)
CONTINUITY OF PROTECTION CONDUCTORS WITH 200mA
Range (Ω): 0.00 ~ 9.99
10.0 ~ 99.9
100 ~ 1999
Resolution (Ω): 0.01
0.1
1
Accuracy: ±(5.0%rdg + 3dgt)
INSULATION RESISTANCE
DC test voltage (V)/ Range (MΩ)
50 / 0.01 ~ 9.99
10.0 ~ 49.9
50.0 ~ 99.9
100 / 0.01 ~ 9.99
10.0 ~ 99.9
100 ~ 199
250 / 0.01 ~ 9.99
10.0 ~ 99.9
100 ~ 249
250 ~ 499
500 / 0.01 ~ 9.99
10.0 ~ 199.9
200 ~ 499
500 ~ 999
1000 / 0.01 ~ 9.99
10.0 ~ 199.9
200 ~ 999
1000 ~ 1999
MECHANICAL CHARACTERISTICS
Dimensions (L x W x H): 225 x 165 x 75mm (9 x 6 x 3in)
Weight (batteries included): 1.2kg (42 ounces)
Mechanical protection: IP40
POWER SUPPLY
Battery type: 6x1.5V alkaline batteries type AA IEC LR06 or 6 x1.2V rechargeable NiMH type AA
Battery life: > 500 tests for each function
Auto power OFF: after 5 minutes’ idling (if activated)
ENVIRONMENTAL CONDITIONS FOR USE
Reference temperature: 23°C±5°C (73°F~41°F)
Operating temperature: 0°C±40°C (32°F~104°F)
Allowable relative humidity: <80%RH
Storage temperature: -10°C±60°C (14°F~140°F)
Storage humidity: <80%RH
Max. operating altitude: 2000m (6562ft)
STANDARD ACCESSORIES
User manual on CD-ROM and quick guide
Calibration report
BORSA75
C2033X
UNIVERSALKIT COMBI
TOPVIEW2006
OPTIONAL ACCESSORIES
SP-0500
VA500
PR400
606-IECN
