DC/AC VOLTAGE MEASUREMENT (LED indications)
Range [V]; ±12, 24, 50, 120, 230, 400, 690, 1000
Resolution [V]: 1
Frequency range [Hz]: 0/40Hz ~ 400Hz
Accuracy: Compliance with IEC/EN61243- 3:2014
Overload protection: 1000VDC/AC
DC/AC VOLTAGE MEASUREMENT (Display indications)
Range [V]: 6 : 1000
Resolution [V]: 1
Frequency range [Hz]: 0/40Hz ~ 400Hz ±(3%rdg + 5dgt)
Accuracy:±(3%rdg + 5dgt)
Overload protection: 1000VAC/DC
AC VOLTAGE MEASUREMENT WITH LOW IMPEDANCE (LoZ)
Range [V]: 6 ~ 1000
Resolution [V]:
Frequency range: 40Hz ~ 400Hz
Input impedance: ca 7kΩ
Overload protection : 1000VAC/DC
AC VOLTAGE WITH 1 WIRE
Range [V]: 100 ~ 1000
Frequency range: 50 ~ 400
Measurement method: 1-wire with contact on metal live parts
Overload protection: 1000VAC
RESISTANCE MEASUREMENT
Range [Ω]: 0 1999
Resolution [Ω]: 1
Accuracy: ±(5.0%rdg+10dgt)
Test current: <30µA
Overload protection: 1000VAC/DC
CONTINUITY TEST
GENERAL SPECIFICATIONS
Dimensions (L x W x H): 270 x 70 x 30mm
Weight (included batteries): 290g
Internal supply: 2x1.5V alkaline batteries type AAA, IEC LR03
Auto Power OFF: after 1minutes of idleness (resistance measurement)
Standard accessories
Carrying bag
Batteries and Manual
