DC voltage: 600.0mV/ 6.000V/ 60.00V/ 600.0V/ 1000V; ±(1.0%rdg+2dgt); 10MΩ;1000VDC/ACrms
AC TRMS voltage:
6.000V/ 60.00V/ 600.0V;±(1.0%rdg+8dgt); ±(2.0%rdg+8dgt); 1000VDC/ACrms
1000V; ±(1.2%rdg+3dgt); ±(2.5%rdg+3dgt); ; 1000VDC/ACrms
DC current: 600.0µA/ 6000µA/ 60.00mA/ 600.0mA; ±(1.0%rdg+3dgt); Fast Fuse 0.8A/1kVAC/DC (inputs mA, µA)
6.000A/ 10.00A; ±(1.5%rdg+3dgt); Fast Fuse 10A/1kVAC/DC (input 10A)
AC TRMS current:
600.0µA/ 60.00mA/ 600.0mA/ 6000µA; ±(1.5%rdg+3dgt); Fast Fuse 0.8A/1kVAC/DC (inputs mA, µA)
6.000A/ 10.00A; ±(2.0%rdg+3dgt); Fast Fuse 10A/1kVAC/DC (inputs 10A)
DIODE TEST: 0.9mA; 2.8V; 1000VDC/ACrms
RESISTANCE AND CONTINUITY TEST:
600.0Ω/ 6.000kΩ/ 60.00kΩ/ 600.0kΩ/ 6.000MΩ; ±(1.0%rdg+4dgt); 2.8V; <100 1000VDC/ACrms
60.00MΩ; ±(2.0%rdg+10dgt); 2.8V; <100Ωl 1000VDC/ACrms
FREQUENCY (Electronic circuits):
9.999Hz/ 99.99Hz/ 999.9Hz/ 9.999kHz/ 99.99kHz/ 999.9kHz/ 9.999MHz;
±(0.1%rdg+2dgt);0.8Vrms min (20% < duty < 80%,<100kHz) 5Vrms min
(20% < duty < 80%, >100kHz); 1000VDC/ACrms
FREQUENCY (Electrical circuits):
10 ÷ 400Hz; ±(1.5%rdg+5dgt); 15Vrms (10Arms ); 1000VDC/ACrms
DUTY CYCLE:
0.1 ÷ 99.9%; ±(1.2%rdg+2dgt); 1000VDC/ACrms
Display: LCD, 3½dgt, 6000 counts, sign, decimal point and bargraph; Automatic polarity indication; Backlight; “OL” over range indication; Response time: 2/s
Features: Data HOLD; MAX/MIN; RANGE; REL; Auto Power OFF after 15 minutes of idleness
Altitude max of use: 2000m
Pollution degree: 2
Insulation: double insulation
Power supply: 1x9V alkaline battery NEDA 1604 IEC 6F22
Dimensions (L x W x H) 175 x 85 x 55mm
Weight (included battery) 390g
Accessories:
ISO9000 calibration certificate
Bag B80
Pair of Leads KIT4000A
Batteries and user manual
