Current measurement: (0-25)mA
Accuracy:±(0.02%R.D+0.005%F.S)
Voltage measurement: (0-25)V
Accuracy:±(0.02%R.D+0.005%F.S)
Temperature compensating range:(0-50)℃
DC output:DC24V(≤30mA) Accuracy: ±1%F.S
Power supply:7.4Vdc Lithium battery power supply and special charger
Connection:M20×1.5 or 1/4"NPT male thread(or customized)
Dimensions:Φ95mmx49mm. Total Height:166mm
Weight:0.75kg
Features
Equipped with rugged ABS plastic
Pressure-transmitting medium including air, oil, and water
6/5-digit LCD screen with backlight
Nine Pressure Units Selectable: kPa, Pa, psi, kgf/cm2, bar, mbar,mmH2O, mmHg, MPa
Zero point, full scale calibration function
7.4Vdc Lithium battery and special charger
Overload and short circuit protection
Light weight, small size, easy operation
Rapid in operation, compatible with computer software
Support Hart Version 5
With max/min Values functions
CE approved
