Specifications
Rated power (KVA/KW): 10/9
Noise level (dBA): 60
Input specification
Nominal voltage (VAC): 380/400/415
Voltage range (VAC): 190-304 or 304-478
Frequency range (Hz): 40-70
Number of phases: 3:1
Output specification
Voltage (VAC): 380/400/415
Frequency (Hz): Battery mode 50/60Hz ± 0.1%; Main mode synchronizes with Bypass
Switching time (second): 0 second
Waveform: Standard sine wave
Battery
Quantity and type: 192VDC, 16PCS
Charging time: reaches 90% within 8 hours of charging
Dimension & Weight
Product dimensions (mm): 440 x 650 x 88 (L x W x H)
Weight: 17kg
Operating environment
Operating temperature: 0ºC – 40ºC
Humidity: 20 – 90% without condensation
