Phase (Degree)
Range: ± 180.00°
Resolution: 0.01°
Frequency(Hz)
Display Resolution: 5 digits
Maximum resolution: 0.001Hz of 10.000Hz to 99.999Hz
Measuring Range: 10 Hz to 1500Hz
Voltage(V)
Ranges (Auto or Manual) (4 range): 60V 150V 300V 600V RMS
Display Resolution: 5 digits
Operating Principle: Digital Calculation True RMS
Frequency Range: 10Hz to 1500Hz
Input impedance: 2 MΩ and 10 pF on all ranges
Effective input range: 20% to 120% of the range
Interface
Standard: RS-232, RS-485
Optional: GPIB
Insulation Resistance: More than 20Mohm at 500Vdc between input terminals and case between case and power line.
Operating Temperature: 5 to 50℃ (41 to 104℉)
Humidity Range: 10 to 90% (relative humidity) non-condensing.
Line Requirements: AC115V or 230V±15%，47 to 63Hz 15VA
Dimensions/Weight: 260x110x360(WxHxD)/4.2kgs net.
Option order Information: PAM-OPT-488: GPIB interface
