Operating voltage [V]: 10...30 DC; (supply class 2 to cULus)
Current consumption [mA]: < 200; (10 V)
Protection class: III
Reverse polarity protection: yes
Power-on delay time [s]: 2
Type of light: red light
Wave length [nm]: 650
Number of inputs and outputs: Number of digital inputs: 1; Number of digital outputs: 2
Trigger: external
Number of digital inputs: 1
Number of digital outputs: 2
Output function: 2 x normally open / normally closed; (parameterisable)
Max. current load per output [mA]: 100
Type of short-circuit protection: pulsed
Overload protection: yes
Measuring distance (Z-direction) [mm]: 150...300
Width of the measuring range (X-direction) at min. measuring distance [mm]: 45; (distance = 150mm)
Width of the measuring range (X-direction) at max. measuring distance [mm]: 90; (distance = 300mm)
Sampling rate [Hz]: 5
Number of profiles which can be stored: 1
Number of regions of interest: 1
Communication interface: IO-Link
Transmission type: COM3 (230,4 kBaud)
IO-Link revision: 1.1
SIO mode: yes
Required master port type: A
Min. process cycle time [ms]: 2.3
Ambient temperature [°C]: -10...55
Storage temperature [°C]: -40...60
Protection: IP 65
Max. immunity to extraneous light [klx]: 20
Weight [g]: 535.8
Dimensions [mm]: 88 x 65 x 28.5
Display: switching status: 1 x LED, yellow; Display operation 1 x LED, green
