Type of movement: orbital
Shaker diameter: 20 mm
Permissible shaking weight (incl. attachment): 7.5 kg
Motor rating input: 45 W
Motor rating output: 10 W
Permissible ON time: 100 %
Speed min (adjustable): 10 rpm
Speed range: 10 - 500 rpm
Speed display: LED
Speed deviation: 1 %
Speed control: 1 RPM steps
Timer: yes
Timer display: 7 segment LED
Time setting min.: 1 s
Time setting range: 1 - 59940 min
Operating mode: timer and continuous operation
Heat output: 1000 W
Set temperature resolution: 0.1 ±K
Control accuracy with sensor (1 vessel 0.5 L H2O, RT 22°C, T=37°C): 0.5 ±K
Temperature display: yes
Temperature range (inlet T>3°C)room temp.: - 10° - 80° °C
connections for external cooling: yes
embedded cooling coil: yes
Operating area inner chamber: 330 x 330 x 258 mm
Total volume inner chamber: 50 l
Raw material housing: Sheet metal powder coat
Raw material hood: PMMA
Raw material front foilpolyester
Raw material front panel: ABS painted
Temperature stability (1 vessel 0.5 L, RT 25°C, T=37°C): 0.05 ±K
Temperature homogenity (5 vessel 0.5 L; RT 25°C, T=37°C): 0.5 ±K
Height with open hood: 875 mm
Dimensions (W x H x D): 465 x 430 x 695 mm
Weight: 37 kg
Permissible ambient temperature: 15 - 32 °C
Permissible relative humidity: 80 %
Protection class according to DIN EN 60529: IP 30
RS 232 interface: yes
USB interface: yes
Voltage: 230 / 115 / 100 V
Frequency: 50/60 Hz
Power input: 1120 W
